Characteristic
■ SAIBO engages in warehouse & logistic industry many years. After several generations of optimization and improvement, the product has solved various problems in the application; SAIBO telescopic fork helps customers reduce time and cost for project:
■ Optimized structure, Accurate positioning, Low deflection at full extension status.
■ The loading width can adjust automatically to be suitable for different specifications of boxes;
■ Stable and reliable performance.
■ Quick response: Experienced technical team provide quick respond;
Parameters
■ Loading width range: 200-614 mm, Effective loading depth: 930mm
■ Max. pick/drop distance: 1444mm, Max. load capacity:50Kg
■ Dimensions (Width*Depth*Height): 1016*1003*232mm, Weight：68Kg
■ Max. extend speed: 1.5m/s, Max. acceleration:1m/s²
■ Motor power: 400W
Main Applications
■ Shuttles for automated warehouse, AGV, MINI load etc.
